1800 mton x 7" Sutton-Breda Aluminum Profile Extrusion Line with Turla Log Saw System: EX-492

1800 mton x 7" Sutton-Breda Aluminum Profile Extrusion Line with Turla Log Saw System: EX-492

orCall +1 (336) 597-2370

Description

1800 mton x 7" Sutton-Breda Aluminum Profile Extrusion Line with Turla Log Saw System: EX-492

  • VERY GOOD CONDITION ... PRESS, HANDLING SYSTEM, AND FINISH SAW SYSTEM !!!
  • VERY NICE TURLA LOG TO BILLET AUTOMATIC SAW SYSTEM


Manufacturer:

- Sutton-Breda and Turla / new 1976, 1996, 2014


Type:

- Direct


Condition:

- Press is still installed and in operation.

- It will be decommissioned September 2020.

- Press revamped in 2011 = hydraulic circuit and PLC system (Allen Bradley)


Specs & Equipment:


TURLA LOG TO BILLET SAW SYSTEM

- Type: automatically sawing of 7" log to programmable billet length

- Max Log length of 7 m (23 ft)

- Condition: Completely Revamped on 2014.

- Saw line is still installed and in operation.

- It will be stopped on August 2020


Turla Equipment

- Log Charging Conveyor

- Log Automatic Saw

- Billet Discharging Conveyor

- Packing station - 525 to 900 mm billet length capacity

- Chip extraction system - cyclone type, 22 kW motor

- Miscellaneous Automatic butt end extractor system

- Automatic billet marker


EXTRUSION LINE

- Extrusion force: 1800 mtons

- Billet Diameter: 178 mm (7")

- Container Diameter: 187 mm (7.36")

- Billet length: 525 - 800 mm (20.7 - 31.5")

- Main Pumps: Rexroth x 4 (plus 1 Aux and 1 overfeed)

- Main Motors: 4 x 161 kW, by Comer

- Billet Heater: Elhaus, new 1976, Gas heated

- Run-out System: Turla, new 1976, 50 m table length, tables = roller and belt type

- Double Puller: Turla, wire drive train

- Stretcher: Turla, 50 mton force

- Cold Saw: Turla, new 1996, max width: 900 mm, max height: 155 mm, max final length: 14 m

- Stacker: Turla, new 1996, Type: - Steel spacers/Magnetic, Max width: 900 mm, Max final length: 14 m

- Die heating oven


CONDITION

Very clean, modern PLC and pumps etc. Really a well maintained line. Drawings and maintenance records included.

Manufacturer: - Sutton-Breda and Turla / new 1976, 1996, 2014 Type: - Direct Condition: - Press is still installed and in operation. - It will be decommissioned September 2020. - Press revamped in 2011 = hydraulic circuit and PLC system (Allen Bradley) Specs & Equipment: TURLA LOG TO BILLET SAW SYSTEM - Type: automatically sawing of 7" log to programmable billet length - Max Log length of 7 m (23 ft) - Condition: Completely Revamped on 2014. - Saw line is still installed and in operation. - It will be stopped on August 2020 Turla Equipment - Log Charging Conveyor - Log Automatic Saw - Billet Discharging Conveyor - Packing station - 525 to 900 mm billet length capacity - Chip extraction system - cyclone type, 22 kW motor - Miscellaneous Automatic butt end extractor system - Automatic billet marker EXTRUSION LINE - Extrusion force: 1800 mtons - Billet Diameter: 178 mm (7") - Container Diameter: 187 mm (7.36") - Billet length: 525 - 800 mm (20.7 - 31.5") - Main Pumps: Rexroth x 4 (plus 1 Aux and 1 overfeed) - Main Motors: 4 x 161 kW, by Comer - Billet Heater: Elhaus, new 1976, Gas heated - Run-out System: Turla, new 1976, 50 m table length, tables = roller and belt type - Double Puller: Turla, wire drive train - Stretcher: Turla, 50 mton force - Cold Saw: Turla, new 1996, max width: 900 mm, max height: 155 mm, max final length: 14 m - Stacker: Turla, new 1996, Type: - Steel spacers/Magnetic, Max width: 900 mm, Max final length: 14 m - Die heating oven

Specifications

ManufacturerSUTTON
ModelExtrusion Line
Year1976
ConditionUsed
Stock NumberEX-492
TypeExtrusion, Aluminum Complete Profile Lines
StatusFor Sale
Type- Direct
