Description
1700 mm Aluminum Cut-to-Length Line: CTL-146
- Complete Aluminum Cut-to-Length line for 1700 mm x 4.0 mm strip
Manufacture:
- Blue Star Ltd / new 1992
- Decommissioned May 2019, Dismantled May 2020
Material:
- Aluminum and its alloys
Strip Width
- 600 - 1700 mm (23.6 - 66.9")
Strip Thickness
- 0.35 - 4.0 mm (.014 - .157")
Line Speed
- 60 mpm max (196.8 fpm)
Hand of Line - Right to Left (as viewed from operator’s side)
Strengths
- Yield Strength: 30 kg/mm2 max
- Tensile Strength: 35 kg/mm2 max
- Shear Strength: 25 kg/mm2 max
Coil Size
- ID - 600 mm (23.6")
- OD - 1825 mm (71.8")
- Weight - 11,600 kg with spool (25,566 lbs)
- Spool size: 595 mm ID x 660 mm OD x 1950 mm width x 975 kg
Cut Sheet
- Length - 600 - 4000 mm max (23.6 - 157.5")
- Stack weight - 3000 kg max (6,612 lbs)
- Stack height - 600 mm max including pallet (23.6")
- Scrap sheet length - 2000 mm max (78.7")
- Cut length tolerances - +/- 1.0 mm (.039")
Specifications
Manufacturer | BLUE STAR LTD. |
Model | Cut-to-Length Line |
Year | 1992 |
Condition | Used |
Stock Number | CTL-146 |
Type | Cut-to-Length, Cut-to-Length Lines |
Status | For Sale |
Material | - Aluminum and its alloys |
