1800 mton x 7" Sutton-Breda Aluminum Profile Extrusion Line with Turla Log Saw System: EX-492

Contact us for price

orCall 1-336-597-2370

Description

Manufacturer: Sutton-Breda, new 1976 Type: Direct Condition: Press is still installed and in operation. It will be decommissioned August 2020. Press revamped in 2011: hydraulic circuit and PLC system (Allen Bradley) Specs & Equipment: TURLA LOG TO BILLET SAW SYSTEM Type: automatically sawing of 7" log to programmable billet length Condition: Completely Revamped on 2014. Saw line is still installed and in operation. It will be stopped on August 2020 Equipment (7 m / 23 ft max log length system): - Logs charging conveyor - Logs Automatic Saw - Billets discharging conveyor - Packing station - 525 to 900mm billet length capacity - Chips extraction system - cyclone type, 22 kW motor Miscellaneous Automatic butt end extractor system Automatic billet marker EXTRUSION LINE Extrusion force: 1800 mtons Billet Diameter: 178 mm (7") Container Diameter: 187 mm (7.36") Billet length: 525 - 800 mm (20.7 - 31.5") Main Pumps: Rexroth x 4 (plus 1 Aux and 1 overfeed) Main Motors: 4 x 161 kW, by Comer Billet Heater: Elhaus, new 1976, Gas heated Run-out System: Turla, new 1976, 50 m table length, Roller + belt tables Double Puller: Turla, wire drive train Stretcher: Turla, 50 mton force Cold Saw: Turla, new 1996, max width: 900 mm, max height: 155 mm, max final length: 14 m Stacker: Turla, new 1996, Type: - Steel spacers/Magnetic, Max width: 900 mm, Max final length: 14 m Die heating oven

Specifications

ManufacturerSutton
Year1976
ConditionUsed
Stock NumberEX-492
ManufacturerSutton Breda
Year of Manufact1976
